Sofar 3-Phase On-Grid Inverter, G4 Series - Sofar125KTLX-G4

Sofar 3-Phase On-Grid Inverter, G4 Series - Sofar125KTLX-G4

by Sofar
SKU SOFAR125KTLX-G4
Request for Quote
₹299,250 - ₹299,250
₹299,250
₹299,250 - ₹299,250
₹299,250
(Incl. GST)

₹285,000 + ₹14,250 GST

Availability:
Request for Quote

Image 1
Image 2
Image 3
Image 4


Delivery Logo Delivery in 3 to 5 days in PAN India

Shipping Logo Shipping Charges: FREE

Image for reference

Technical Datasheet Download Datasheet
380V / 400V / 415V 380V / 400V / 415V
AC: type II AC: type II
Active Power Adjustable Range 0~100%
AFCI Yes
Allowable Relative Humidity Range 0~100%
Ambient Temperature Range -30??C~+60??C
Anti-Islanding Protection Yes
Application Industrial Rooftop Solar
Brand Sofar
Category String Inverter
Communication RS485/ WiFi
Cooling Smart air cooling
DC Reverse Polarity Protection Yes
DC Switch Yes
Display LCD & Bluetooth +APP
European Efficiency 0.983
Inverter Type On-Grid
kW 125
Leakage Current Protection Yes
Max. Apparent Power 125kVA@45??C / 110kVA@50??C
Max. Efficiency 0.986
Max. Input MPPT Current 10*40A
Max. Input Short Circuit Current 10*50A
Max. Input Voltage 1100V
Max. Operating Altitude 4000m (>3000m derating)
Max. Output Current 190A@380V / 181.2A@400V / 174A@415V
MPPT Operating Voltage Range 180V~1000V
Number Of DC Inputs 2 for each MPPT
Number Of MPPTs 10
Output Frequency Range 45~55Hz/55~65Hz
Output Voltage Range 310Vac-480Vac
Phase Three
Power Factor 1 (+/-0.8 adjustable)
PV-Array String Fault Monitoring Yes
Rated Input Voltage 625V
Rated Output Frequency 50/60Hz
Rated Output Power 110kW
Rated Output Voltage 3/N/PE
Self-Consumption At Night <2W
SPD PV: type II
Start-Up Voltage 200V
Sub Category C&I
THDi <1%(@100%P)
Topology Transformerless

Massage Icon Report an issue with this product
Sofar 3-Phase On-Grid Inverter, G4 Series
Warranty:- 5 Years
Dimension (W??H??D):- 970??695??325mm
Weight:- 75kg,
Country of Origin:- China
Packaging Type:- Box
